Home Living Window LED Screen
INTRODUCTION
| Pixel Pitch | 2.5mm | 2mm | 1.8mm | |||||||||
| LED type | SMD2121 | SMD1515 | SMD1515 | |||||||||
| Pixel Density | 160000dots/m² | 250000dots/m² | 308025dots/m² | |||||||||
| Resolution/Set | 256 x 256dots | 320 x 320dots | 355 x 355dots | |||||||||
| Size/Set | 640*640mm | 640*640mm | 640*640mm | |||||||||
| Scan Mode | 1/32 scan | 1/40scan | 1/43scan | |||||||||
| Weight | 15kg/Set | |||||||||||
| Waterproof rate | IP30 (Front) IP31 (Rear) | |||||||||||
| Brightness | 800CD/m2 | 800CD/m2 | 800CD/m2 | |||||||||
| View Distance | ≥2.5m | ≥2.0m | ≥1.8m | |||||||||
| Viewing Angle (H/V) | 140°/120° | |||||||||||
| Gray Scale | 14bit | |||||||||||
| Color type | 68 Billion | |||||||||||
| Max.Power Consumption | 200W/Cabinet | 230W/Cabinet | 240W/Cabinet | |||||||||
| Ave .Power Consumption | 70W/Cabinet | 77W/Cabinet | 80W/Cabinet | |||||||||
| Refresh rate | >1920HZ | |||||||||||
| Gamma | -5.0~+5.0 | |||||||||||
| Applied environment | Indoor | |||||||||||
| Controller | Synchronous display with control PC by DVI | |||||||||||
| Support Input | Composite ,S-Vide ,Component ,VGA,DVI,HDMI,HD_SDI | |||||||||||
| Power input | AC220 or AC110 50/60HZ, FSP GROUP | |||||||||||
| Environment | temperature -10℃~+50℃，humidity 10~90% RH | |||||||||||
| Operating Life | 50,000hours | |||||||||||
