Power

Input voltage range: 100-240V ~ 50/60Hz

Power:625W

Light Source

Light source: beam end: 5 x 120W RGBL LED

Outer ring LED: 120x 0.5W RGB LED

Luminous flux of lamp: 13000 lumens

Expected life of light source: 20000 hours * data provided by light source supplier

Optical System

Beam angle: 3 °- 30 °

Spot angle: 4 °- 35 °

Control System

Control panel: LCD display

Control protocols: DMX512, RDM, Art-Net, Master-slave, Sound Run, Auto Run

DMX channel mode: 3

Control channel: 23CH/41CH/71CH

Software upgrade: upgrade software over a DMX connection

Pan / Tilt

Pan running angle: 59 °

Tilt running angle: 221 °

Automatic correction of Pan / Tilt position out of step

Pan / Tilt: 16 bit precision scan

Other Effects

Outstanding strobe effect with variable speed

0-100% smooth dimming

Excellent color mixing function

Excellent color macro effect

Fast linear focusing function

Electrical and Connectors

Power sockets: Powercon input / output

Signal sockets: 3-pins DMX socket input / output

Body

Appearance: metal, black

IP Rating: IP20

Product Dimensions: 1019.6x153.37x228.76mm

Net Weight:27.8kg
